Dhyana 6060BSI
Ultra-large BSI sCMOS camera with CXP high-speed interface.
- 95%@580nm Peak QE
- 10μm x 10μm Pixel Size
- 6144 x 6144 Resolution
- 26.4fps@12-bit STD
- CoaXPress 2.0
詢 價
產品介紹
Dhyana 6060BSI is a large sCMOS cameras customized for for Astrophysics. They can realize high-speed and high dynamic imaging and quantitative analysis in a large field of view, with high reliability and adaptability to complex environments.
-
寬光譜成像，高信噪比
采用背照式sCMOS技術，具有200nm-1100nm的寬光譜響應能力，峰值量子效率高達95%QE，讀出噪聲僅3e, 具有優異的弱光成像能力和高信噪比優勢。
-
86毫米大靶面
86mm對角線傳感器提供了驚人的成像效率。它可以一次拍攝廣闊的視野畫面，無需拼接，提供更高的數據吞吐量和識別精度。
-
CXP Interface Drives Speed
Leveraging the world's leading interface standard for high-speed imaging, you can keep up with dynamic imaging subjects. CoaXPress offers very high speed and precision data transmission, with the simplicity and long cable lengths of coaxial cable.
技術參數 >
- Model: Dhyana 6060BSI
- Sensor Type: BSI sCMOS
- Sensor Model: Gpixel GSENSE6060BSI
- Color/Mono: Mono
- Array Diagonal : 86.8 mm
- Resolution: 36MP, 6144(H) x 6144(V)
- Pixel Size: 10μm x 10μm
- Effective Area: 61.4mm x 61.4mm
- Peak QE: 95%@580nm
- Frame Rate: 26.4fps@12-bit STD; 11.3fps@12-bit HDR; 8.6fps@14-bit STD
- Full-Well Capacity: Typical: 102ke-
- Dynamic Range: 90dB
- Shutter Type: Rolling
- Readout noise: 3e-(Median)
- Exposure time: 12μs-300s
- DSNU: 1.5e-
- PRNU: 0.2%
- Cooling Method: Air & Liquid
- Max. Cooling: Air: -35℃，Liquid: -45℃
- Cooling temperature: Air: (Ambient at +20 ): -15°C; Liquid: -25°C@20°C
- Dark current: Air: 0.25e-/pixel/s; Liquid: 0.15e-/pixel/s
- Data Interface: CoaXPress2.0
- Binning: 2x2, 4x4
- ROI: Support
- Timestamp Accuracy: 1μs
- GPS: Support
- Trigger Mode: Hardware & Software
- Output Trigger Signals: Exposure, Global, Readout, High level, Low level
- Trigger Interface: SMA
- Data Bit Depth: 12bit, 14bit, 16bit
- Optiona Interface: User-customization
- Power Supply: 12V/10A
- Power Consumption: ＜100W
- Dimensions : φ160mm x 164mm
- Weight: ~4kg
- Software: Samplepro/MAXIMDL/Labview/Matlab/EPICS
- SDK: C/C++/C#
- Operating System: Windows/Linux
- Operating Environment: Working: Temperature -35~45℃/Humidity 0~95%;
Storage: Temperature -35~60℃/Humidity 0~95%
顯示更多
應用方向 >
Download >
-
Dhyana 6060BSI Brochure
-
Dhyana 6060BSI Dimension
-
Software-Mosaic V1.6.8
-
Plugin-Labview ( with user guide )
-
Plugin-Matlab ( with user guide )
-
Plugin-MetaXpress ( with user guide )
-
Plugin-Micromanager ( with user guide )
-
Driver-TUCam Camera Driver V1.4.0.8
